7. HDMI Via Graphics and Sound Cards
The other place where you’ll occasionally find HDMI ports—and will now typically find DVI-I with HDCP support—is on higher-end graphics cards manufactured since 2005: the NVidia 8500, 8600, and newer 8800 chipsets and AMD/ATI 24xx and newer chipsets. Invariably, if these cards accept audio input for “real HDMI output” (video plus audio, that is) it will be in the form of a 4-pin SPDIF header block or some kind of SPDIF input jack: RCA for coaxial, TOSLINK for optical. Here again, this puts the current generation of graphics cards at the same disadvantage in handling high-definition, high-resolution sound as other technologies that involve SPDIF—there’s simply insufficient bandwidth to enable transfer of Dolby Digital Plus, Dolby TrueHD, DTS-HD High Resolution, DTS-HD Master Audio, or high bandwidth forms of LPCM across the link.
Where do sound cards fit into this picture?
Currently, plenty of vendors are “talking” about HDMI sound output and high-definition audio support, but nobody sells a sound card that can output HDMI audio in a form that could feed into an HDMI output. Asus has announced its Xonar HDAV1.3 card for release sometime in Q3 2008 (they showed the card off at Computex in Taiwan on June 4, and have issued a press release with some interesting product information as well), and Auzentech has been promising an HDMI audio card since late 2006. But they, and other big players in the sound card world, such as Creative, M-Audio, HT Omega, are all struggling with the lack of a standard interface for moving high-definition audio around inside a PC. They also must deal with combining high-bandwidth audio with high-definition video inside an environment that meets HDCP requirements at all steps in the processing chain, as that specification clearly requires.
So far, the Asus Xonar HDAV1.3 appears to offer the best hope for high-def PC audio enthusiasts who want to move Dolby TrueHD or DTS Master Audio from a PC-based Blu-ray player into a properly-equipped receiver to make the most of 6 or 8 channel surround sound outputs. The Xonar HDAV will actually pick up the video through an HDMI input (presumably from an HDMI-equipped graphics card), then add the high-def audio to an HDMI output stream before shipping that output stream that combines high-def audio and video through its HDMI output to another device downstream. Interestingly, Asus is bundling the ArcSoft Total Media Theatre decoder with this product, according to reports from Computex (and confirmed by mention in the press release cited in the preceding paragraph) with this card as well.
As we write this story, Asus was unable to provide a precise release date or pricing information (we expect the Xonar HDAV 1.3 to cost upwards of $300 based on its capabilities and components). Even more interesting, the HDAV 1.3 will be available with a daughter card for high-quality analog audio, as well as its powerful digital audio handling capabilities, and even supports user swap-out of its operational amplifiers (op-amps) for audiophiles who might wish to use other plug-in modules to replace the Burr-Brown PCM1796, 123 dB SNR units installed by default. Figure 1 below shows the Xonar HDAV1.3 card in profile view; Figure 2 shows the unit (and its daughter card) installed in two PCI-e x1 motherboard slots.
Figure 1
This is another situation where even the highest-fidelity PC audio adapters currently available offer two sets of audio outputs: 6 or 8 channel analog, or optical and/or coaxial SPDIF. Either way, this rules out native transport of high-bandwidth Dolby or DTS formats, and also prevents transmission of high-bandwidth LPCM audio streams as well.
