8. Under The Covers

• DSM-520 Wireless HD...
• • AllAmericanDirect.com
  • $219.99
• • Mwave.com
  • $235.54

Figure 14: The DSM-520 with the cover off

As you can see in Figure 14, D-Link didn't really need all that space inside the DSM-520's enclosure. They apparently just wanted the device to fit nicely in an entertainment center. Figure 15 is a close up of the DSM-520 motherboard.

Figure 15: The motherboard (click for full-resolution image).

You can see that the main CPU is a Sigma Designs EM8620l, which has an ARM core and does all the A/V heavy lifting as well. I couldn't find any specific information on it, but an ALPHA Networks WMP-G09 mini-pci card provides the wireless capabilities. A RealTek Redsonic. A network fingerprint scan identified the operating system as: "Linux 2.4.X|2.5.X," so the internal operating is most likely Linux-based, but a fingerprint scan can be misinterpreted.
